Description
Chromag’s best value stem for 35mm bars.
- Cold forged in Taiwan
- Equally robust as Chromag’s CNC’d stems
- Rounder edges and smoother contours
- More DH/Enduro focused than the HiFi
- 35mm bar mount
SPECS:
- Process // 3D Forging
- Material // Premium 6061 Alloy
- Lengths // 35/50mm
- Rise // 0º
- Clamp Size // 35mm
- Stack Height // 38mm
- Steerer // 1 1/8″
- Weight // 203g (50mm)
FORGING:
Forging is a process in which a lump of raw material called a slug is compressed into a desired shape using tooling in a press. Forging produces extremely strong parts as the grain structure of the metal flows with the shape of the geometry.
Downsides of forging are that it is not as accurate as CNC Machining, therefore some aspects of the part still require machining such as the threads for the screws, and the faces which require high tolerance such as the bar interface or steerer bore.
Forging is generally much quicker than CNC Machining and can produce much less waste if near net forging is used, in whereby the slug is cast to closely resemble the final shape of the part.
Generally chromag’s forged parts are less expensive than their CNC Machined parts.
